Ace 304 Hydraulic Driven Cast Iron Pump with 2" Suction x 1-1/2" Discharge | FMC-200-HYD-304

Ace FMC-20-HYD-304 Hydraulic Pump – High-Capacity Cast Iron Centrifugal Sprayer Pump for Agricultural and Industrial Applications

The Ace FMC-20-HYD-304 Hydraulic Pump is a powerful and durable solution for agricultural and industrial spraying applications. Engineered to efficiently handle a wide range of fluids, including water, insecticides, herbicides, liquid fertilizers, emulsions, wettable powders, and more, this high-capacity centrifugal pump ensures consistent, reliable performance.

Constructed from premium cast iron, the pump's body is built to withstand corrosion and chemical exposure, making it ideal for tough, long-lasting operation in challenging environments. With a maximum flow rate of 200 GPM and hydraulic motor capabilities of 11 GPM, the Ace FMC-20-HYD-304 delivers efficient spraying with up to 120 PSI for a wide variety of tasks.

Designed for easy integration with your equipment, this hydraulic-driven pump can be conveniently mounted on tractors or sprayers, utilizing the vehicle's hydraulic system and leaving the PTO available for other uses. Equipped with a stainless steel shaft and wear ring, the pump offers excellent corrosion resistance and durability for a longer service life.

Perfect for high-demand agricultural and industrial spraying tasks, the Ace FMC-20-HYD-304 Hydraulic Pump ensures superior performance and reliability with every use.

Key Features:

• High-capacity centrifugal pump for agricultural and industrial fluid application

• Max flow rate of 200 GPM and hydraulic motor flow of 11 GPM

• Maximum pressure of 120 PSI

• Built with durable, corrosion-resistant cast iron for long-lasting performance

• Convenient mounting on tractors or sprayers using the vehicle's hydraulic system

• Equipped with stainless steel shaft and wear ring for excellent corrosion resistance and durability

Ideal for a wide range of spraying applications, the Ace FMC-20-HYD-304 is your go-to hydraulic centrifugal pump for efficient, hassle-free operation.

Part Breakdown



Reference Number	Part Number	EDP Number	Description	Required
1	BAC-53	41110	Pipe plug	4
1	41120	41120	Pipe plug, stainless steel (optional)	4
2	7AC-14-CCW	41526	Volute, 2” x 1-1/2”	1
3	BAC-23-A	40391	Nut, 3/8” NF, cad plated	1
3	BAC-23-B-SS	40393	Nut, 3/8” NF, SS (optional)	1
4	BAC-24-HYD-SS	40400	Washer, 3/8” star, stainless steel	1
4	BAC-24-B-SS	42702	Washer, 3/8” SS, vibration proof (optional)	1
5	BAC-26-200-P	40434	Impeller, with extended keyway, thermoplastic	1
5	BAC-26-200-CI	40433	Impeller,with extended keyway, cast iron (optional)	1
5	BAC-26-200-SS	40436	Impeller,with extended keyway, 316 stainless steel (optional)	1
6 (1)	BAC-4A	40005	O-ring, body seal	1
7 (1)	BAC-7V	40151	Seal, mechanical, Viton (includes 40160 “O” Ring)	1
7 (2)	BAC-7SC	40152	Seal, mechanical, silicon carbide (includes 40160 “O” Ring) (optional)	1
7A	40160	40160	O-ring, shaft seal	1
8	BAC-14-HYD-300A	40314	Mounting frame (for -300A series hydraulic motor)	1
9	40950	40950	Cap screw, 3/8” NC x 3/4” hex head	4
9	40930	40930	Cap screw, 3/8” NC x 3/4” hex head, stainless steel (optional)	4
10	41330	41330	Cap screw, 5/16” N. C. x 3/4” hex head, motor to pump	4
11	BAC-54	41130	Slinger	1
12	BAC-33	40810	Snap ring, internal, BAC-14 mounting frame	2
13	BAC-37	40870	Ball Bearing, sealed, BAC-6 shaft	2
14	BAC-32	40790	Snap ring, external, BAC-6 shaft	2
15	BAC-32-S	40795	Spacer for BAC-6 shaft	1
16	BAC-25	40425	Key, 1/8” x 1/8” x 13/16”, extended keyway	1
17	BAC-6-HYD-200-SS	40063	Shaft, extended keyway, tang, stainless steel	1
18	S300	40162	Seal support spacer for 300 Series HYD motor, effective 6/00	1
19	BAC-75-HYD-304N	41343	Hydraulic motor, 11 GPM, effective 5/13	1
19	BAC-75-HYD-304A-12SAE	41426	Hydraulic motor, 11 GPM, #12 SAE end ports (optional)	1
20	41875	41875	O-ring, #8 SAE fitting	1
21	41445	41445	O-ring, #10 SAE fitting	1
22	BAC-80-8SAE	41455	Body, restrictor orifice, #8SAE x 1/2” NPT	1
23	41448	41448	O-ring, orifice insert	1
24	BAC-79-8	41447	Orifice insert, restrictor insert, 0.125	1
25	41442	41442	Reverse check assembly, #10 SAE x 1/2” NPT	1
26	LS-304N	41429	Flow limiter (optional)	1
(1)	RK-FMC	52700	Repair kit for FMC series pump	-
(2)	RK-FMCSC	52706	Repair kit for FMC series pump with silicon carbide shaft seal	-
#	RK-BAC-75-HYD-300-L	41362	Repair kit for 300 Series -L motor	-
